Small goods lifts
Small goods lifts are a compact, adaptable and dependable way to move smaller loads between floors. They are used above all in catering, retail, healthcare and office buildings, and also in housing.
They allow safe and efficient movement of food, crockery, goods, documents, medicines, equipment and other small loads. Their compact design and the range of versions mean they can be fitted into tight spaces in existing buildings.
The car can be non-through, through or corner-through, and depending on the space available the drive can sit above the shaft, below it or beside it.
Advantages
- compact and space-efficient,
- adapts to a range of spatial conditions,
- loads from 5 to 300 kg,
- speeds up to 0.45 m/s,
- non-through, through or corner-through car,
- several options for siting the drive,
- also suits existing buildings,
- quick and straightforward installation,
- dependable, long-lasting operation.
Technical data
| Load | 5 to 300 kg |
|---|---|
| Speed | 0.20 / 0.25 / 0.30 / 0.45 m/s |
| Car | non-through, through or corner-through |
| Drive position | above, below or beside the shaft |
| Car width | 300 to 1,000 mm |
| Car depth | 320 to 1,000 mm |
| Car height | 600 to 1,200 mm |
Where they are used
Small goods lifts particularly suit:
- catering: moving food, crockery and supplies,
- retail: moving goods between floors,
- healthcare: moving medicines, materials and equipment,
- offices: moving documents and small items,
- housing: moving food, shopping and other loads.
At DVG INŽENIRING we match the installation to the building, the use and the space available, so a workable answer can usually be found even where space is tight.
